Navigator 4.5

Book A Demo

The Navigator 4.5 is a self-powered push-around scissor lift achieving a working height of 4.5 metres and is rated for both indoor and outdoor use. Simply step in, turn the handle and elevate to your chosen working height with materials and tools giving you zero downtime and power-free working 24/7. Carbon Zero, meaning no electrics,batteries or hydraulics.

Key Features:

  • Lightweight Compared to Conventional Scissor Lifts
  • Lifts both Operative and Materials to Height
  • Fits through a Standard Door Frame
  • Minimum Repair & Maintenance Costs
  • Zero Operational Costs & Carbon Zero
  • Tool Tray & Tethering Points fitted as Standard
  • Patent Pending
  • Colour: Orange (RAL2004) & Grey (RAL7040)
  • Material: Steel & Aluminium
  • Replaceable Decals

Safety Features & Benefits:

  • Anti Climb Vertical Guardrail – No Need to Purchase Additional Anti Climb Guards
  • Transport and Deck Lock – No Risk of Movement or Self Elevation
  • Anti Surf Brakes – No Risk of Movement
  • Optional Tethering Accessories for Tools – Ensures that no tools fall from height
  • Outriggers – Standard wind rating for indoor/outdoor use
  • Winch Point & Fork Lift Skids – For easy Loading & Lifting
  • Step into the Platform, no Climbing – Ensures the safety of the Operator
  • Optional Brick Guard
  • Optional Outriggers

Applications:

  • Mechanical & Electrical
  • Fitout
  • Refurbishments
  • Facility Management
  • Data Centres
  • Shipping
  • Aviation Maintenance

Standards:

  • UKCA Approved
  • BS EN 280 accredited
Specifications:
  • Working Height - 4.5M
  • Working Platform - 2.5M
  • Working Footprint - 1.05(L) x 0.72(W)M
  • Platform Dimensions - 0.75(L) x 0.68(W)M
  • Closed Dimensions - 1.05(L) x 0.72(W) x 1.79(H)M
  • Safe Working Load - 150KG
  • Maximum Side Force - 200N
  • Maximum Wind Speed (outdoors) - 12.5 M/S
  • Maximum Gradient - 1 Degree
  • Maximum Load per Fixed Wheel - 800KG
  • Maximum Load per Swivel Wheel - 2000KG
  • Machine Weight - 295KG
Navigator 6.0 Specification Sheets, Manuals & Certifications:
Specification Sheet
Operating & Maintenance Manual
8673010721 MEWP Type Examination Certificate
5104010721 MEWP Type Examination Certificate
